SINGLE-ENDED TRIODE OTL HEADPHONE AMPLIFIER ZERO FEEDBACK | NONINVERTING
Specifications
Headphone Impedance: 32-600 ohms Gain: 8 (18 dB) Frequency Response: 10Hz-200KHz, -3dB Maximum Output: 30V P-P THD: Less than 0.5%, 20Hz-20KHz, at 1V Topology: Class-A single-ended triode, zero feedback, noninverting, single voltage gain stage Tube Complement: 6N1P dual triode input, 6N6P dual triode output, 1 each per channel Power Consumption: 40W Size: 9 x 6.75 x 3.25” Weight: 7 lbs
